Samsung Galaxy Note 20 Ultra 5G

Samsung Galaxy Note 20 Ultra 5G Specifications

• Key Specs
• Rear Camera 108 MP + 12 MP + 12 MP
• Front Camera 10 MP
• Battery 4500 mAh
• Display 6.9 inches (17.53 cm)
• Processor Samsung Exynos 9 Octa 990
• RAM 12 GB

• Battery
• USB Type-C Yes
• Removable No
• Type Li-ion
• Quick Charging Yes, Fast, 25W
• Wireless Charging Yes
• Capacity 4500 mAh
• TalkTime Up to 24 Hours(4G)

• Design
• Ruggedness Dust proof
• Height 164.8 mm
• Waterproof Yes, Water resistant (up to 30 minutes in a depth of 1.5 meter), IP68
• Width 77.2 mm
• Weight 208 grams
• Build Material Back: Gorilla Glass
• Colours Mystic Bronze, Mystic Black, Mystic White
• Thickness 8.1 mm

• Display
• Resolution 1440x3088 px (QHD+)
• Refresh Rate 120 Hz
• HDR 10 / HDR+ support Yes, HDR 10+
• Screen Protection Corning Gorilla Glass, Glass Victus
• Screen to Body Ratio (calculated) 92.94 %
• Bezel-less display Yes with punch-hole display
• Touch Screen Yes, Capacitive Touchscreen, Multi-touch
• Screen Size 6.9 inches (17.53 cm)
• Aspect Ratio 19.3:9
• Display Type Dynamic AMOLED
• Pixel Density 494 ppi
• Brightness 1500 nits

• Front Camera
• Video Recording 3840x2160 @ 30 fps 1920x1080 @ 30 fps
• Sensor CMOS
• Autofocus Yes, Phase Detection autofocus, Dual Pixel autofocus
• Resolution 10 MP f/2.2, Wide Angle, Primary Camera(26 mm focal length, 3.2" sensor size, 1.22µm pixel size)
• Camera Setup Single

• General
• Brand Samsung
• Custom UI Samsung One UI
• Launch Date August 7, 2020
• Operating System Android v10 (Q)

• Main Camera
• Flash Yes, LED Flash
• OIS Yes
• Video Recording 7680x4320 @ 24 fps 3840x2160 @ 30 fps 1920x1080 @ 60 fps 1280x720 @ 960 fps
• Resolution 108 MP f/1.8, Wide Angle (79° field-of-view), Primary Camera(26 mm focal length, 1.33" sensor size, 0.8µm pixel size)12 MP f/3.0, Periscope Camera(120 mm focal length, 1µm pixel size)12 MP f/2.2, Ultra-Wide Angle Camera(13 mm focal length, 2.55" sensor size, 1.4µm pixel size)
• Camera Setup Triple
• Image Resolution 12000 x 9000 Pixels
• Sensor ISO-CELL
• Shooting Modes Continuous Shooting High Dynamic Range mode (HDR)
• Autofocus Yes, Phase Detection autofocus, Dual Pixel autofocus, Laser autofocus
• Settings Exposure compensation, ISO control
• Camera Features Digital Zoom Auto Flash Face detection Touch to focus

• Multimedia
• Loudspeaker Yes
• FM Radio No
• Audio Jack USB Type-C

• Network & Connectivity
• Network Support 5G Supported in India, 4G Supported in India, 3G, 2G
• SIM Slot(s) Dual SIM, GSM+GSM
• Wi-Fi Features Wi-Fi Direct, Mobile Hotspot
• SIM 1 5G Bands: FDD N1 / N3 / N5 / N7 / N8 / N28 TDD N40 / N77 / N78 4G Bands: TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41) / 1900(band 39) FD-LTE 2100(band 1) / 1800(band 3) / 2600(band 7) / 900(band 8) / 700(band 28) / 1900(band 2) / 1700(band 4) / 850(band 5) / 700(band 17) / 850(band 18) / 850(band 19) / 800(band 20) / 1900(band 25) / 850(band 26) 3G Bands: UMTS 1900 / 2100 / 850 / 900 MHz 2G Bands: GSM 1800 / 1900 / 850 / 900 MHz GPRS: Available EDGE: Available
• Wi-Fi Yes, Wi-Fi 6 (802.11 b/g/n/ax) 5GHz, MIMO
• SIM Size SIM1: Nano, SIM2: Nano (Hybrid)
• Bluetooth Yes, v5.0
• USB Connectivity Mass storage device, USB charging
• GPS Yes with A-GPS, Glonass
• VoLTE Yes
• SIM 2 4G Bands: TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41) / 1900(band 39) FD-LTE 2100(band 1) / 1800(band 3) / 2600(band 7) / 900(band 8) / 700(band 28) / 1900(band 2) / 1700(band 4) / 850(band 5) / 700(band 17) / 850(band 18) / 850(band 19) / 800(band 20) / 1900(band 25) / 850(band 26) 3G Bands: UMTS 1900 / 2100 / 850 / 900 MHz 2G Bands: GSM 1800 / 1900 / 850 / 900 MHz GPRS: Available EDGE: Available
• NFC Yes

• Performance
• Architecture 64 bit
• CPU Octa core (2.73 GHz, Dual core, M5 Mongoose + 2.5 GHz, Dual core, Cortex A76 + 2 GHz, Quad core, Cortex A55)
• RAM Type LPDDR5
• RAM 12 GB
• Graphics Mali-G77 MP11
• RAM type LPDDR5
• Chipset Samsung Exynos 9 Octa 990
• Fabrication 7 nm

• Sensors
• Fingerprint Sensor Position On-screen
• Other Sensors Light sensor, Proximity sensor, Accelerometer, Barometer, Compass, Gyroscope
• Stylus Yes
• Fingerprint Sensor Yes
• Fingerprint Sensor Type Ultrasonic

• Storage
• Internal Memory 256 GB
• Expandable Memory Yes, Up to 1 TB
• User Available Storage Up to 221 GB
• USB OTG Yes
• Storage Type UFS 3.1
